All-O-Matic AVW-665 V-Groove Steel Gate Wheel

All-O-Matic AVW-665 V-Groove Steel Gate Wheel

The All-O-Matic AVW-665 is a 6-inch V-Groove power wheel constructed from C45 solid steel with a chrome-plated finish. Rated for gates up to 5,000 lbs, it features pre-lubricated double precision sealed bearings for maintenance-free operation and delivers 30% more torque transfer compared to cast iron wheels. A 5/8-inch bolt with nut is included for installation.

Key Features

• 6-Inch V-Groove design engineered for smooth sliding gate movement
• C45 solid steel construction with chrome-plated finish for exceptional durability
• 5,000 lb load capacity for heavy-duty gate applications
• Pre-lubricated double precision sealed bearings — maintenance-free, no grease fittings required
• 30% more torque transfer than cast iron wheels
• 5/8-inch bolt with nut included for secure installation

Specifications

• Model: AVW-665
• Wheel Diameter: 6 inches
• Material: C45 solid steel with chrome-plated finish
• Bolt Size: 5/8 inch (nut included)
• Load Capacity: 5,000 lbs
• Maintenance: Maintenance-free, no grease fittings required

The All-O-Matic AVW-665 is a reliable heavy-duty wheel solution for high-load sliding gate systems.
