All-O-Matic MACH-PRIME Column Mount Swing Gate Operator Sing
The All-O-Matic MACH-PRIME is a column mount swing gate operator handling gates up to 8 feet wide and 500 lbs, featuring a continuous duty brushless motor, integrated battery backup, and solar compatibility. Made in the USA.
Overview
The All-O-Matic MACH-PRIME is an automatic column mount swing gate operator engineered for simplicity, versatility, and convenience. It delivers smooth and virtually silent gate movement and supports gates up to 8 feet wide and 500 lbs. The control board features programmable logic and an advanced charge controller optimized for solar applications, supporting 12/24V solar panels up to 80 watts.
Key Features
- Continuous Duty, Brushless Motor — 24 VDC gearhead motor for reliable, quiet operation
- Adjustable Gate Speed — Opens 90° in 14 to 25 seconds
- Power Flexibility — Compatible with 115/230 VAC single phase or 24 VDC solar panel input
- Integrated Battery Backup — Includes (2) 7Ah 12VDC batteries with up to 250 cycle backup capacity
- Includes 1 Photo Eye
- Emergency Release — Manual release key
- Made in USA
- Warranty — 3-year residential / 7/5-year limited manufacturer warranty
- Breaker requirement: 20 amp dedicated
Specifications
- Max Gate Weight: 500 lbs.
- Max Gate Length: 8 feet
- Operational Voltage: 24 VDC
- Gate Speed: Adjustable 14–25 seconds per 90° opening
- Duty Cycle: 30 minutes (Intermittent)
- Battery Backup Capacity: Up to 250 cycles
- Temperature Range: -20 to 160°
- Operator Dimensions: D 5" x L 15" x H 5.75"
- Control Box Dimensions: H 16.750" x L 19.6875" x D 7.875"
- Operator Shipping Weight: 36 lbs. (includes arm)
- Control Box Shipping Weight: 42 lbs.
- Manufacturer Part Number: MACH-PRIME-SINGLE
The All-O-Matic MACH-PRIME is a capable, USA-made solution for residential swing gate automation with flexible power options and integrated battery backup.
