All-O-Matic MAGNA-Q-MQ-19 Barrier Gate Operator

Overview

The All-O-Matic MAGNA-Q-MQ-19 is a direct-drive, pad-mounted barrier gate operator built for continuous-duty use in commercial, industrial, and solar-compatible security applications. Powered by a 24VDC brushless DC motor, it ships with a 15 ft 7 in aluminum barrier arm, integrated battery backup, and a photoeye — ready for demanding, high-cycle access control environments. The powder-coated 6061 aluminum cabinet is rated for outdoor use and requires no springs or counterweights for operation.

Key Features

• 24VDC brushless DC motor for smooth, quiet, continuous-duty operation
• Adjustable gate speed from 2.5 to 4.5 seconds
• Integrated battery backup — up to 350 cycles with 15 ft arm (2 × 12V 7Ah batteries included)
• Supports 120VAC, 208/240VAC, or 24VDC solar input
• LCD interface with onboard diagnostics and USB firmware update port
• Breakaway arm mechanism minimizes damage on vehicle impact
• DIP-switch selectable left or right-hand opening
• Built-in 120VAC accessory outlet
• Manual spindle crank for emergency release
• Cycle counter and 7-day timer for maintenance tracking
• UL 325 compliant for Class II, III, and IV usage
• Single-phase input; solar ready
• Universal controller compatible — Doorking 1800-500

Specifications

• Motor: 24VDC Brushless DC (BLDC), 0.5 HP
• Input Voltage: 115V / 208V / 240V (single-phase) or 24VDC solar
• Battery Backup: 2 × 12V 7Ah (included)
• Gate Speed: 2.5–4.5 seconds (adjustable)
• Standard Arm Length: 15 ft 7 in
• Maximum Arm Length: 19 ft 8 in (with extension)
• Cabinet Dimensions: 11" W × 14" D × 42" H
• Cabinet Material: Powder-coated 6061 aluminum
• Operator Weight: 120 lbs (without arm)
• Duty Cycle: Continuous
• Mounting Type: Pad Mounted
• Mechanism: Direct Drive
• Weatherproof: Rated for outdoor usage
• UL/ETL Certification: Yes (UL 325, Class II, III, IV)
• Warranty: 10 years on cabinet; 3 years on electrical/mechanical components

Included Accessories

• 15 ft 7 in aluminum barrier arm (MQ-15A)
• Photoeye
• 2 × 12V 7Ah batteries

Compatible Accessories

• MQ-4AE – 49 in extension for total arm length of 19 ft 8 in
• MQ-AAHW – Articulating (folding) arm hardware for MQ-15A arm
• MQ-LED15 – LED strip for 15 ft arm
• MQ-LED19 – LED strip for 19 ft arm
• MQ-EDGE15 – LED + safety edge combination for 15 ft arm
• MQ-EDGE19 – LED + safety edge combination for 19 ft arm
• MQ-BAB – Replacement breakaway bracket
• AOM PRIME VD1 – Plug-in loop detector
• AOM-RED EYE 2 Kit – Retro-reflective photoeye
• 24VDC Solar Panel (min 55W) – For off-grid installations

The All-O-Matic MAGNA-Q-MQ-19 delivers a modular, all-weather barrier solution engineered for high-security, high-traffic vehicle access control.
