All-O-Matic MQ-EDGE-15 LED Strip & Safety Edge Kit

Overview

The All-O-Matic MQ-EDGE-15 is a combination LED illumination and safety edge kit purpose-built for the MAGNA Q barrier gate system. It installs into the bottom channel of the MQ-15A arm assembly, integrating directly with the operator's logic via AUX Relay 2 to deliver both visual gate status indication and physical obstruction detection in a single, pre-wired solution.

Key Features

• Combines LED illumination and safety edge sensor in one kit
• Designed for the 15 ft 7 in MAGNA Q barrier arm (MQ-15A)
• Installs in the bottom channel of the barrier arm
• Pre-wired for clean integration through factory grommets
• Includes 12VDC adapter that plugs into the operator's 120VAC outlet
• Compatible with MAGNA Q AUX Relay 2 logic functions (selectable trigger modes)
• Rated for outdoor usage
• UL/ETL certified

Wiring Connections

• Red — 12VDC (+)
• Black — 12VDC (−)
• White — MAGLOCK
• Yellow — SOLENOID

Specifications

• Voltage: 12V
• Mounting Type: Slide-In-Rail | Plug-In
• Arm Fit: 15 ft 7 in
• Weatherproof Rating: Rated for Outdoor Usage
• UL/ETL Certification: Yes

Compatibility

• Compatible with MAGNA Q MQ-19 barrier operators with aluminum arms only
• Fits MQ-15A arm assembly

The All-O-Matic MQ-EDGE-15 delivers a clean, factory-integrated solution for perimeter safety and night visibility on MAGNA Q barrier gate systems.
