All-O-Matic MQ-EDGE-19 LED Strip & Safety Edge Combo

Overview

The All-O-Matic MQ-EDGE-19 is a combination LED illumination and safety edge kit purpose-built for MAGNA Q barrier gate systems. Designed for arms extended to 19 ft 8 in using the MQ-4AE accessory, it installs into the bottom channel of the barrier arm and integrates with the operator's logic via AUX Relay 2. A 12VDC adapter is included and plugs into the operator's 120VAC outlet for clean, factory-ready installation.

Key Features

• Combines LED illumination and safety edge sensor for visibility and entrapment protection
• Fits arms extended to 19 ft 8 in using the MQ-4AE accessory
• Installs in the bottom channel of the barrier arm
• Includes 12VDC adapter that plugs into the operator's 120VAC outlet
• Pre-wired for integration through factory grommets
• Compatible with MAGNA Q AUX Relay 2 logic functions (selectable trigger modes)
• Rated for outdoor usage
• UL/ETL certified

Specifications

• Power Input: 12VDC via included transformer
• Mounting Type: Slide-In-Rail, Plug-In
• Weatherproof Rating: Rated for outdoor usage
• UL/ETL Certification: Yes

Wiring

• Red to 12VDC (+)
• Black to 12VDC (−)
• White to MAGLOCK
• Yellow to SOLENOID

Compatibility

• Compatible with MAGNA Q MQ-19 barrier operators with aluminum arms only
• Requires MQ-4AE accessory for 19 ft 8 in arm extension

The All-O-Matic MQ-EDGE-19 delivers an integrated safety and visibility solution designed specifically for extended MAGNA Q barrier arm installations.
