All-O-Matic MQ-LED15 LED Strip Kit for 15' Arm
The All-O-Matic MQ-LED15 is an LED strip kit designed for MAGNA Q barrier arms, sized for the 15 ft 7 in arm. It installs into the bottom channel of the arm and includes a 12VDC power supply for use with the operator's built-in 120VAC outlet.
Overview
The All-O-Matic MQ-LED15 is a purpose-built LED strip kit for the MAGNA Q barrier gate system. Sized specifically for the 15 ft 7 in MAGNA Q arm, it slides into the bottom channel of the aluminum arm and illuminates to improve nighttime visibility and perimeter safety. The kit includes a 12VDC power supply that plugs into the operator's built-in 120VAC outlet and integrates with the system's onboard logic through AUX Relay 2 configuration.
Key Features
- Designed exclusively for MAGNA Q barrier arms
- Fits the 15 ft 7 in MAGNA Q arm
- Installs into the bottom channel of the aluminum arm via slide-in-rail mounting
- Includes 12VDC power supply compatible with the operator's 120VAC outlet
- Pre-wired for clean routing into the operator cabinet
- Compatible with MAGNA Q's safety edge sensors
- Improves nighttime visibility and perimeter safety
- Rated for outdoor usage
- UL/ETL certified
Specifications
- Input Voltage: 12VDC (via included adapter)
- Mounting Type: Slide-In-Rail, Plug-In
- Mounting Location: Bottom channel of MAGNA Q barrier arm
- Weatherproof Rating: Rated for outdoor usage
- UL/ETL Certification: Yes
- Connection Points: Red to 12VDC positive, black to 12VDC negative, white to MAGLOCK (Relay 2), yellow to SOLENOID (Relay 2)
Compatibility
- Compatible with all MAGNA Q 15 ft 7 in Arm systems
- Requires AUX Relay 2 configuration through LCD settings
- Installation tip: Use a small amount of soapy water to ease LED strip insertion into the arm channel
The All-O-Matic MQ-LED15 delivers clean, fully integrated illumination for MAGNA Q barrier arms, enhancing driver awareness and perimeter safety.
