All-O-Matic MQ-LED19 LED Strip Kit for 19' Arm
The All-O-Matic MQ-LED19 is an LED strip kit designed for 19 ft 8 in MAGNA Q barrier arms, installing into the bottom channel of the arm and powered by an included 12VDC power supply via the operator's built-in 120VAC outlet.
Overview
The All-O-Matic MQ-LED19 LED strip kit is purpose-built for the extended 19 ft 8 in MAGNA Q barrier arm. It slides into the bottom channel of the aluminum arm and illuminates to improve nighttime visibility and perimeter safety during gate operation. The kit includes a 12VDC power supply that plugs directly into the operator's 120VAC outlet, and activation is controlled through AUX Relay 2 configuration via the LCD settings.
Key Features
- Designed specifically for MAGNA Q barrier arms
- Fits the 19 ft 8 in MAGNA Q arm
- Installs into the bottom channel of the aluminum arm using a slide-in-rail mount
- Includes 12VDC power supply for use with the operator's 120VAC outlet
- Pre-wired for clean routing into the operator cabinet
- Compatible with MAGNA Q's safety edge sensors
- Improves nighttime visibility and perimeter safety
- Requires AUX Relay 2 configuration through LCD settings
- Rated for outdoor usage
- UL/ETL Certified
Technical Specifications
- Input Voltage: 12VDC (via included adapter)
- Mounting Type: Slide-In-Rail | Plug-In
- Mounting Location: Bottom channel of MAGNA Q barrier arm
- Connection Points: Red to 12VDC positive, black to 12VDC negative, white to MAGLOCK (Relay 2), yellow to SOLENOID (Relay 2)
- Weatherproof Rating: Rated for Outdoor Usage
- UL/ETL Certification: Yes
Compatibility
- Compatible with All MAGNA Q MQ-19 systems
- Compatible with MAGNA Q safety edge sensors
Installation Note: Use a small amount of soapy water to ease LED strip insertion into the arm channel.
The All-O-Matic MQ-LED19 delivers clean integration and enhanced driver awareness with fully programmable illumination using the operator's onboard logic.
