All-O-Matic OH-200DC-PRO 1/2 HP DC Overhead Gate Operator

Overview

The All-O-Matic OH-200DC-PRO is a heavy-duty overhead gate operator engineered for high-cycle commercial and industrial applications. Powered by a 24VDC brushless motor and managed by an advanced ALL-BLDC Pro control board, the OH-200DC-PRO delivers quiet, reliable overhead access with built-in power redundancy. A 10 ft rail is included, and the unit accepts 115VAC or 230VAC (selectable) or solar input.

Key Features

• Supports gates up to 800 lbs and 20 ft in length
• 24VDC brushless motor with continuous-duty rating
• Integrated battery backup — includes (2) 7Ah 12V batteries; provides approximately 100 cycles on a fully charged battery
• Soft start/stop motion with programmable gate speed
• Onboard diagnostics with LCD display and firmware updates via USB
• Advanced ERD system for obstruction detection with adjustable force settings
• Pre-wired loop rack for plug-in detectors
• Solar-ready with MPPT charge controller (up to 80W, 24VDC)
• UL 325 compliant for Classes I–IV
• Lockable quick-release carriage for manual operation
• 10 ft rail included; custom lengths available up to 16 ft
• Operating temperature: -40°F to 160°F

Specifications

• Model: OH-200DC-PRO
• Motor Type: Brushless DC Motor
• Horsepower: 0.5 HP
• Voltage: 115V or 230VAC (selectable); Solar 24VDC up to 80W
• Max Gate Weight: 800 lbs
• Max Gate Length: 20 ft
• Gate Speed: 14–26 seconds (6.5 ft–8 ft gate)
• Duty Cycle: Continuous
• Battery Backup: (2) 7Ah 12V batteries included (~100 cycles)
• Gearbox Ratio: 40:1
• Chain Size: #41NP
• Sprockets: 41B15 (5/8" bore), 2.5" gearbox pulley, 2" motor pulley
• Dimensions: 13" W × 144" L × 8" H
• Breakers Required: 20A dedicated
• UL Classification: UL 325 Class I–IV
• Mounting Type: Ceiling Mounted
• Mechanism: Chain Drive
• Warranty: 5 years commercial
• Temperature Rating: -40°F to 160°F

Compatibility

• Universal Controller Compatible: Doorking 1800-500
• Loop detector support via pre-wired loop rack

The All-O-Matic OH-200DC-PRO is built for facilities that demand quiet, secure, and uninterrupted gate access — even during power outages.
