All-O-Matic SW-300DC-PRO 1/2 HP DC Swing Gate Operator
The All-O-Matic SW-300DC-PRO is a 1/2 HP brushless DC swing gate operator supporting gates up to 20 feet wide and 1,200 lbs., with integrated battery backup and solar power compatibility. Made in the USA.
Overview
The All-O-Matic SW-300DC-PRO is a continuous-duty swing gate operator powered by a 24VDC brushless 1/2 HP motor that delivers smooth, quiet, and maintenance-free performance. It handles gates up to 20 feet wide and 1,200 lbs., and operates on 115/230VAC single-phase power or a 24VDC solar panel input. An integrated battery backup system keeps the operator running for up to 250 cycles during a power outage. The SW-300DC-PRO is Made in the USA.
Key Features
- Brushless DC Motor: Continuous duty, 24VDC, 1/2 HP — requires zero maintenance
- Adjustable Gate Speed: Opens 90° in 17–25 seconds (adjustable)
- Integrated Battery Backup: Includes (2) 7Ah 12VDC batteries — up to 250 cycles of backup operation
- Solar Compatible: Accepts 24VDC solar panel input in addition to 115/230VAC single-phase power
- Matrix-III Control Board: Features programmable relay, leaf delay, and slow start/stop algorithm
- Includes 1 Photo Eye
- Quick Release Arm for emergency manual operation
- Wireless Primary/Secondary capability included
- Made in the USA
- Warranty: 7-year residential / 5-year commercial limited manufacturer warranty
Specifications
- Model: SW-300DC-PRO
- Brand: All-O-Matic
- Motor: 24VDC brushless, 1/2 HP
- Power Source: 115/230VAC single phase or 24VDC solar panel
- Operational Voltage: 24VDC
- Duty Cycle: Continuous
- Max Gate Weight: 1,200 lbs.
- Max Gate Length: 22 feet
- Gate Speed: Adjustable, 17–25 seconds per 90° opening
- Gearbox Ratio: 60:1
- Battery Backup: (2) 7Ah 12VDC batteries — up to 250 cycles
- Temperature Range: -40° to 160°
- Dimensions (W x L x H): 12" x 17" x 25.5"
- Breaker Requirement: 20 amp dedicated
- Belt Size: 4L-370 (AX35)
- Main Sprocket Size: 40A54TX2 with torque limiter
- Chain Size: 40NP
- Gearbox Sprocket: 41B22X7/8
- Gearbox Pulley: 8" with 5/8" bore
- Motor Pulley: 2" with 5/8" bore
- Manufacturer Part Number: SW300-DC-PRO
The All-O-Matic SW-300DC-PRO delivers powerful, reliable swing gate automation with solar flexibility and a maintenance-free brushless motor backed by an industry-leading warranty.
