All-O-Matic SW-320DC-PRO Swing Gate Operator
The All-O-Matic SW-320DC-PRO is a solar-ready swing gate operator handling gates up to 700 lbs and 14 feet, with integrated battery backup and an under-arm design.
Overview
The All-O-Matic SW-320DC-PRO Swing Gate Operator automates residential and light commercial gates while keeping a low profile with its under-arm installation. Powered by a 24 VDC gearhead motor, it supports gates up to 700 lbs and 14 feet long, with an adjustable opening speed of 13 to 25 seconds per 90-degree travel. A UL/ETL certified design and proven all-weather construction make it a dependable choice across a wide range of climates.
Key Features
- Under-Arm Design: Keeps the operator arm low and discreet to preserve the gate's appearance
- Gate Capacity: Supports gates up to 700 lbs and 14 feet long
- Adjustable Speed: Opening time adjustable from 13 to 25 seconds per 90-degree opening
- Battery Backup Included: Two 7Ah 12VDC batteries provide up to 250 cycles during power outages
- Solar-Ready: Compatible with solar power for off-grid operation
- Quick Release Arm: Enables manual operation during emergencies
- All-Weather Operation: Rated for temperatures from -40°F to 160°F
- UL/ETL Certified: Yes
- Mounting: Pad mounted or post mounted
- Included Accessories: Photoeye
Specifications
- Max Gate Weight: 700 lbs
- Max Gate Length: 14 feet
- Motor: 24 VDC gearhead motor — Brushless DC Motor
- Power Supply: 115/230 VAC or 24 VDC solar option
- Gate Speed: Adjustable 13–25 seconds per 90-degree opening
- Battery Backup: Two 7Ah 12VDC batteries, up to 250 cycles
- Operating Temperature: -40°F to 160°F
- Mechanism: Gear Drive
- Installation Type: Residential | Commercial | HOA
- Warranty: 5 years residential, 3 years light commercial
Compatible Accessories
- PRIME VD-1 Loop Detector — Automated vehicle detection
- Solar Panel — Enables off-grid solar operation
- AML-1200B Mag Lock — Electromagnetic lock for enhanced security
- GH-1500 Hinges — Heavy-duty hinges for proper gate support
- Fire Boxes — For integrating fire safety features
The All-O-Matic SW-320DC-PRO delivers reliable, discreet swing gate automation with the flexibility of solar power and the assurance of built-in battery backup.
