All-O-Matic SW-325-DC-PRO DC Swing Gate Operator

Overview

The All-O-Matic SW-325-DC-PRO is a UL 325 2018 compliant DC swing gate operator engineered for heavy commercial and industrial gates with continuous duty cycle performance. Designed to move gates up to 2,000 lbs. and 22 feet in length, its underarm design positions the gate bracket at the bottom of the gate to preserve the gate's appearance. Mounting options — Pad Mount or Post Mount — must be specified at time of ordering.

Key Features

• Brushless DC motor: 24 VDC, ½ HP — smooth, quiet, powerful, and zero maintenance required
• Integrated battery backup: Up to two weeks of uninterrupted operation during a power outage; includes (2) 7Ah 12VDC batteries with up to 250 cycles backup capacity
• Adjustable gate speed: 14–25 seconds per 90° opening
• Solar power capability: Compatible with 115/230 VAC single phase and 24 VDC solar panel power options
• Control board features: Programmable relay, leaf delay, and slow start/stop algorithm
• Easy slide quick release arm: Designed for fast and straightforward installation
• Continuous duty cycle
• Breaker requirement: 20 amp dedicated

Specifications

• Max Gate Weight: 2,000 lbs.
• Max Gate Length: 22 feet
• Motor: 24 VDC brushless – ½ HP
• Gate Speed: Adjustable 14–25 seconds per 90° opening
• Battery Backup Capacity: Up to 250 cycles
• Battery: Integrated, (2) 7Ah 12VDC batteries
• Temperature Range: -40 to 160°
• Gearbox Ratio: 750:1 with internal clutch
• Dimensions (W x L x H): 19" x 25.5" x 21"
• Shipping Weight: 160 lbs. + 30 lbs. arm
• Power Options: 115/230 VAC single phase and 24 VDC solar panel
• Duty Cycle: Continuous
• Breaker Requirement: 20 amp dedicated
• Emergency Release: Easy slide quick release arm
• Compliance: UL 325 2018
• Warranty: 7-year residential / 5-year commercial

The All-O-Matic SW-325-DC-PRO delivers the durability and reliability demanded by high-traffic commercial and industrial gate applications.
