All-O-Matic T24-PRIME Toro Prime Actuator Arm
The All-O-Matic T24-PRIME Toro Prime Actuator Arm is a continuous duty swing gate actuator with integrated battery backup, solar compatibility, and support for gates up to 8’ x 1,600 lbs. Made in the USA with a 4-year residential / 3-year commercial limited warranty.
Overview
The All-O-Matic T24-PRIME Toro Prime Actuator Arm is a modern swing gate actuator designed for residential and light commercial applications. It features an integrated uninterruptible power supply, a keyed manual release for emergency access, and a control board with programmable logic and an advanced charge controller enhanced for solar use. It accepts 12/24V solar panels up to 80 watts. Replaces part number T24A.
Key Features
- Continuous duty operation
- Adjustable gate speed: 15–20 seconds per 90° opening
- Integrated battery backup with (2) 7Ah 12VDC batteries — up to 450 cycles
- Solar compatible: accepts 12/24V solar panels up to 80 watts
- Programmable logic control board with advanced charge controller
- Keyed manual release for emergency access
- Includes 1 photo eye
- Made in the USA
- 4-year residential / 3-year commercial limited manufacturer warranty
Specifications
- Model: T24-PRIME
- Brand: All-O-Matic
- Power Source: 115/230 VAC single phase or 24VDC solar panel
- Operational Voltage: 24VDC
- Duty Cycle: Continuous
- Gate Speed: Adjustable, 15–20 seconds per 90° opening
- Battery Backup: Integrated, (2) 7Ah 12VDC batteries, up to 450 cycles
- Temperature Range: -40° to 160°
- Breaker Requirement: 20 amp dedicated
- Arm — Fully Retracted: 38–39”
- Arm — Fully Extended: 59”
- Emergency Release: Keyed manual release
Gate Compatibility
- 8’ gate — up to 1,600 lbs
- 12’ gate — up to 1,200 lbs
- 16’ gate — up to 800 lbs
- 18’ gate — up to 600 lbs
The All-O-Matic T24-PRIME delivers reliable, continuous-duty swing gate automation built and backed in the USA.
