AES KEY-AUX-PBK-US Auxiliary Pedestal Keypad Panel
SKU
ae-key-aux-pbk-us
The AES KEY-AUX-PBK-US is an Auxiliary Pedestal Mount Keypad Panel that supports connection of up to 6 auxiliary units, with an IP55 weather rating and a 2-year manufacturer's warranty.
Overview
The AES KEY-AUX-PBK-US Auxiliary Pedestal Mount Keypad Panel expands your access control setup by connecting up to 6 auxiliary units. Relays 1 and 2 are located on the master unit, while relays 3 through 8 are distributed across the auxiliary units. Units are wired using 5 cores of Cat 5 cable, and the system supports a mix of keypads and card reader units within a single installation.
Key Features
- Connect up to 6 auxiliary units in one setup
- Supports a mix of keypads and card reader units in a single configuration
- DDA LEDs on each auxiliary unit indicate correct or incorrect code/card use
- Relay on every auxiliary unit, configurable via dip switch
- Keypad tones and confirmation sounds are adjustable on auxiliary units
- Units wired via 5 cores of Cat 5 cable
Specifications
- Power: 24V DC
- Current: 300mA / 2A Peak | 100mA per auxiliary unit
- Weather Rating: IP55
- Relay Type: 2 x N/C & N/O Contacts
- Total Permanent Keypad Codes: 250
- Total Permanent Prox Cards: 250
- Time-Restricted Codes/Cards: 250
- Temporary Codes/Cards: 50
- Manufacturer's Warranty: 2 years
The AES KEY-AUX-PBK-US is a dependable auxiliary keypad panel built for flexible, multi-point access control installations.
