BD Loops MEGGER Analog Megohmmeter Loop Tester
The BD Loops MEGGER is an Analog Megohmmeter and Insulation Tester designed to properly test inductive loops for insulation faults and shorts to ground — something a standard multimeter cannot do.
Overview
The BD Loops MEGGER is the correct tool for loop testing. Unlike multimeters, which only check continuity, the MEGGER is an Insulation Tester — capable of detecting a nick in the loop wire's insulation that causes the loop to short to ground. This analog design displays a numeric megohm reading on its pin, allowing installers to track and monitor loop performance over time rather than relying on a simple pass/fail light indicator.
To obtain a megohm reading, connect one lead to the loop and the other lead to ground.
Key Features
- Analog Megohmmeter / Insulation Tester with a built-in AC Volt Meter (0–600V ACV)
- Displays a numeric megohm reading — trackable over time to monitor loop condition
- Identifies insulation faults and shorts to ground that multimeters cannot detect
What's Included
- Batteries
- Quick Start Instructions for Testing Loops
- In-depth Instructions for Testing Loops
- Testing Record Booklet
- Carrying Case
The BD Loops MEGGER gives installers the data they need to properly diagnose and document loop health on every job.
