BD Loops SC24-300 Preformed 3/16" Saw-Cut Loop
The BD Loops SC24-300 is a preformed 3/16" saw-cut inductance loop in a 4'x8' or 6'x6' size with 300' of lead-in wire, made with 16 AWG copper wire and rated for direct burial use.
Overview
The BD Loops SC24-300 is a complete preformed saw-cut inductance loop featuring a 4'x8' or 6'x6' loop size with 300 feet of lead-in wire. Built with 16 AWG copper wire and rated for direct burial use, it includes a durable outer jacket that protects and tightly binds the inner conductors. Designed for saw-cut installations where a 3/16" or wider slot is cut into concrete or asphalt, the loop wire is stuffed into the slot and sealed with loop sealant.
Key Features
- Durable outer jacket provides an extra layer of protection for both the loop and lead-in.
- Backer-rod built into the wire — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
- Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting.
- Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting the lead-in run.
- Requires 30–40% less loop sealant compared to a 1/4" wide groove.
- Loop can be made up to 4' smaller — cuts don't need to be exact.
- Each loop is tested 3 ways before leaving the factory.
- Compatible with any brand of loop detector.
Specifications
- Model: SC24-300
- Loop Size: 4'x8' or 6'x6'
- Lead-In Length: 300 feet
- Wire Gauge: 16 AWG copper
- Saw-Cut Width Required: 3/16" minimum
- Recommended Cut Depth: 1-1/4" – 1-1/2"
- Direct Burial Rated: Yes
Compatibility
BD Loops SC24-300 will work with any brand of loop detector. A loop detector is required for any loop circuit to function.
The BD Loops SC24-300 delivers professional-grade reliability in a preformed format built for efficient, accurate saw-cut installation.
