BD Loops SC 36-300 Preformed Saw-Cut Inductance Loop

Overview

The BD Loops SC36300 is a preformed saw-cut inductance loop featuring a 6x12 loop size and 300 feet of lead-in wire. Constructed with 16 AWG copper wire and rated for direct burial, it includes a durable outer jacket that protects and binds both the loop and lead-in conductors. Designed for installations where a 3/16" or wider slot is cut into concrete or asphalt, the loop wire is placed into the saw-cut slot and sealed with loop sealant.

Key Features

• Durable outer jacket provides an extra layer of protection over both loop and lead-in.
• Tested 3 ways before leaving the factory.
• Built-in backer-rod — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
• Tightly bound lead-in wires in a protective outer jacket, eliminating the need for twisting.
• Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting of the lead-in run required.
• Loop fills a larger percentage of the groove, requiring 30–40% less sealant versus a 1/4" wide groove.
• Cuts don't need to be exact — any BD Loops preformed saw-cut loop can be made up to 4 feet smaller.
• Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass.

Specifications

• Model: SC36300
• Loop Size: 6x12
• Lead Wire Length: 300 feet
• Wire Gauge: 16 AWG copper
• Installation Type: Saw-cut (3/16" or wider slot)
• Burial Rating: Direct burial

The BD Loops SC36300 is engineered for reliable, professional saw-cut loop installations in concrete or asphalt surfaces.
