BD Loops SC 40-150 Preformed Saw-Cut Inductance Loop

Overview

The BD Loops SC40150 is a preformed saw-cut inductance loop designed for installations where a 3/16" or wider slot is cut into concrete or asphalt, the loop wire is placed into the slot, and sealed with loop sealant. This loop comes in a 6x14 size with 150 feet of lead wire. Built with 16 AWG copper wire and rated for direct burial, every SC40150 includes a durable outer jacket that protects and tightly binds both the loop and lead-in conductors.

Key Features

• Durable outer jacket provides an extra layer of protection for both the loop and lead-in wire.
• Backer-rod built into the wire — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
• Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting.
• Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting the lead-in run required.
• Requires 30–40% less loop sealant compared to a 1/4" wide groove, due to the loop filling a larger percentage of the groove.
• Cuts don't need to be exact — any BD Loop can be made up to 4' smaller, allowing conservative cuts that still fit every time.
• Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass.
• Tested 3 ways before leaving the factory.

Specifications

• Model: SC40150
• Loop Size: 6x14
• Lead Wire Length: 150 feet
• Wire Gauge: 16 AWG copper
• Installation Type: Saw-cut (3/16" or wider slot)
• Burial Rating: Direct burial

The BD Loops SC40150 delivers a professional, reliable saw-cut loop solution engineered for consistent performance and simplified installation.
