BD Loops SC 44-150 Saw-Cut Inductive Loop 6x16 150ft Lead
The BD Loops SC44150 is a preformed saw-cut inductance loop sized 6x16 with 150 feet of lead wire, built with 16 AWG copper wire and rated for direct burial use.
Overview
The BD Loops SC44150 is a preformed saw-cut inductance loop featuring a 6x16 loop size and 150 feet of lead-in wire. Constructed with 16 AWG copper wire and rated for direct burial, this loop includes a durable outer jacket that protects and tightly binds both the loop and lead-in conductors. Designed for saw-cut installations where a 3/16" or wider slot is cut into concrete or asphalt, the loop wire is inserted into the slot and sealed with loop sealant.
Key Features
- Durable outer jacket provides an extra layer of protection for both the loop and lead-in wire.
- Factory tested 3 ways before leaving the facility.
- Built-in backer-rod — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
- Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting.
- Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting the lead-in run.
- Loop fills a larger percentage of the groove, requiring 30–40% less sealant compared to a 1/4" wide groove.
- Cuts don't need to be exact — any BD Loop can be made up to 4 feet smaller for a reliable fit.
- Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass.
Specifications
- Model: SC44150
- Loop Size: 6x16
- Lead Wire Length: 150 feet
- Wire Gauge: 16 AWG copper
- Installation Type: Saw-cut (3/16" or wider slot)
- Burial Rating: Direct burial
The BD Loops SC44150 delivers a reliable, professional-grade saw-cut loop solution engineered for consistent performance in concrete and asphalt installations.
