BD Loops SC 52-250 6x20 Preformed Saw-Cut Loop 250ft Lead
The BD Loops SC52250 is a 6x20 preformed saw-cut inductance loop with 250 feet of lead-in, built with 16 AWG copper wire and rated for direct burial use.
Overview
The BD Loops SC52250 is a complete preformed saw-cut inductance loop featuring a fixed 6x20 loop size and 250 feet of lead-in. Constructed with 16 AWG copper wire and rated for direct burial, it includes a durable outer jacket that protects and binds the inner conductors for both the loop and lead-in run. Designed for saw-cut installations where a 3/16" or wider slot is cut into concrete or asphalt, the loop wire is placed into the slot and sealed with loop sealant.
Key Features
- Durable outer jacket protects both loop and lead-in conductors
- Each loop is tested 3 ways before leaving the factory
- Backer-rod is built into the wire — no separate backer-rod needed when installed in a 3/16" saw-cut groove
- Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting
- Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting of the lead-in run required
- Requires 30–40% less sealant to seal the groove compared to a 1/4" wide groove
- Cuts don't need to be exact — any BD Loop can be made up to 4' smaller for a reliable fit every time
- Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass
Specifications
- Model: SC52250
- Loop Size: 6x20
- Lead Length: 250 feet
- Wire Gauge: 16 AWG copper
- Burial Rating: Direct burial
- Required Slot Width: 3/16" or wider
The BD Loops SC52250 delivers a professional, factory-tested solution for saw-cut loop installations requiring a long lead-in run.
