BD Loops SC 60-100 Preformed Saw-Cut Inductance Loop

Overview

The BD Loops SC60100 is a preformed saw-cut inductance loop designed for installations where a 3/16" or wider slot is cut into concrete or asphalt. The loop wire is placed into the saw-cut slot and sealed with loop sealant. It features a durable outer jacket that protects and tightly binds the inner conductors, and is made with 16 AWG copper wire rated for direct burial use. Loop size is 6x24 with a 100' lead wire.

Key Features

• Durable outer jacket provides an extra layer of protection for both the loop and lead-in wire.
• Each loop is tested 3 ways before leaving the factory.
• Backer-rod is built into the wire — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
• Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting.
• Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting of the lead-in run required.
• Loop fills a larger percentage of the groove, requiring 30–40% less sealant versus a 1/4" wide groove.
• Cuts don't need to be exact — any BD Loop can be made up to 4' smaller for a reliable fit every time.
• Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass.

Specifications

• Model: SC60100
• Loop Size: 6x24
• Lead Wire Length: 100'
• Wire Gauge: 16 AWG copper
• Minimum Slot Width: 3/16"
• Burial Rating: Direct burial

The BD Loops SC60100 is engineered for reliable, professional saw-cut loop installations with less sealant, less labor, and a precise fit.
