BD Loops SC 60-50 Saw-Cut Inductive Loop 6x24 50' Lead

Overview

The BD Loops SC6050 is a preformed saw-cut inductance loop with a fixed 6x24 loop size and 50' lead-in wire. Constructed with 16 AWG copper wire and rated for direct burial, the SC6050 features a durable outer jacket that protects and binds the inner conductors. Designed for installations where a 3/16" or wider slot is cut into concrete or asphalt, then sealed with loop sealant.

Key Features

• Durable outer jacket provides an extra layer of protection for both loop and lead-in wire
• Triple-tested — every loop is tested 3 ways before leaving the factory
• Built-in backer-rod — no separate backer-rod required when installed in a 3/16" saw-cut groove
• Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting
• Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting the lead-in run
• Requires 30–40% less sealant to seal the groove compared to a 1/4" wide groove
• Loop can be made up to 4' smaller — cuts don't need to be exact
• Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass

Specifications

• Model: SC6050
• Loop Size: 6x24
• Lead Wire Length: 50'
• Wire Gauge: 16 AWG copper
• Burial Rating: Direct burial
• Required Slot Width: 3/16" or wider

The BD Loops SC6050 delivers a reliable, professionally engineered saw-cut loop solution built to perform in demanding installations.
