BD Loops SC 72-50 6x30 Preformed 3/16" Saw-Cut Loop

Overview

The BD Loops SC7250 is a preformed saw-cut inductance loop featuring a fixed 6x30 size with a 50' lead-in. Constructed with 16 AWG copper wire and rated for direct burial, this loop is designed for saw-cut installations where a 3/16" or wider slot is cut into concrete or asphalt. The loop wire is placed into the slot and sealed with loop sealant. A durable outer jacket protects and tightly binds both the loop and lead-in conductors.

Key Features

• Durable outer jacket provides an extra layer of protection for both the loop and lead-in run.
• Backer-rod is built into the wire — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
• Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting.
• Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting of the lead-in run required.
• Loop fills a larger percentage of the groove, requiring 30–40% less sealant compared to a 1/4" wide groove.
• Each loop is tested 3 ways before leaving the factory.
• Cuts don't need to be exact — any BD Loop can be made up to 4' smaller for installation flexibility.
• Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass.

Specifications

• Loop Size: 6x30
• Lead Length: 50'
• Wire Gauge: 16 AWG copper
• Minimum Slot Width: 3/16"
• Burial Rating: Direct burial

The BD Loops SC7250 delivers reliable detection performance with professional-grade construction built to last in demanding installations.
