BD Loops SC 84-50 6x36 Preformed 3/16" SawCut Loop

Overview

The BD Loops SC8450 is a preformed saw-cut inductance loop featuring a fixed 6x36 loop size with a 50ft lead-in. Constructed with 16 AWG copper wire and rated for direct burial, it is designed for installations where a 3/16" or wider slot is cut into concrete or asphalt, filled with the loop wire, and sealed with loop sealant. A durable outer jacket protects and tightly binds both the loop and lead-in conductors.

Key Features

• Durable outer jacket provides an extra layer of protection for both the loop and lead-in.
• Built-in backer-rod — no separate backer-rod needed when installed in a 3/16" saw-cut groove.
• Lead-in wires are tightly bound in a protective outer jacket, eliminating the need for twisting.
• Both loop and lead-in fit into a 3/16" wide saw-cut groove — no double cutting the lead-in run.
• Loop fills a larger percentage of the groove, requiring 30–40% less sealant compared to a 1/4" wide groove.
• Each loop is tested 3 ways before leaving the factory.
• Cuts do not need to be exact — any BD Loop can be made up to 4' smaller for installation flexibility.
• Compatible with the BD-LS flat 3/16" sealant tip for a smooth, even seal in a single pass.

Specifications

• Loop Size: 6x36
• Lead-In Length: 50ft
• Wire Gauge: 16 AWG copper
• Saw-Cut Groove Width: 3/16" or wider
• Burial Rating: Direct burial

The BD Loops SC8450 delivers a reliable, professionally engineered preformed loop solution built for consistent performance in saw-cut installations.
