BFT 2618083 Pedestrian Swing Gate Single Kit

Overview

The BFT E5 BT A12 UL (model 2618083) is a reversible electromechanically automated pedestrian swing gate opener designed for residential and apartment building applications. Its compact design and articulated sliding arm allow installation on pillars, columns, and gate posts, including tight spaces. The opener is certified to ANSI/BHMA A156.19 for low-energy pedestrian operation and is U-Link compatible. A photo eye is required and is included in this kit.

Key Features

• U-Link compatible
• Compact design with articulated sliding arm
• D-Track Dynamic Path Tracking for safe operation in all weather conditions
• Absolute Encoder limit switch
• Push&Go Mode — a simple push initiates full opening
• Certified to ANSI/BHMA A156.19 for low-energy pedestrian operation

Specifications

• Actuator Voltage: 24V DC
• Input Voltage: 120V
• Power Consumption: 100W
• Maximum Gate Length: 4.25 ft
• Maximum Gate Weight: 175 lbs.
• Opening Time: 6.5 seconds
• Use Frequency: 100 cycles/hour
• Control Board: Thalia UL
• Operation: Reversible

Kit Includes

• (1) BFT E5 BT A12 UL Gate Opener Motor
• (1) Articulated Arm
• (1) 120V Thalia UL Control Board with 10" x 12" Fiberglass Enclosure Box
• (1) Pair Polarized Reflective Photo Eye Kit with Weather Hood

Compatibility

• U-Link compatible
• Requires pairing with a photo eye (included)

The BFT 2618083 is a professionally installed solution for single pedestrian swing gate automation.
