BFT P935011-00013 LUX 2B UL/CSA 120V Hydraulic Operator

Overview

The BFT P935011-00013 LUX 2B is a hydraulic operator built for hinged gate leaves up to 6 ft (2 m) wide and 661 lbs (300 kg) in weight. It features an all-aluminium structure with high-resistance anodising treatment and is rated for very intensive frequency of use. The unit carries both UL and CSA certification and is designed for demanding professional installations.

Key Features

• All-aluminium structure with high-resistance anodising treatment
• Open/close hydraulic locking system on both closure and opening
• Hydraulic clutch impact reaction
• Triangle key release
• Rated for very intensive frequency of use
• IP57 protection rating
• Work-time type limit switch

Technical Specifications

• Motor voltage: 120 V (UL/CSA)
• Max. gate wing width: 6 ft (2 m)
• Max. gate wing weight: 661 lbs (300 kg)
• Useful rod stroke: 10 inch (270 mm)
• Maximum opening angle: 123°
• Cycle time: 17 s
• Locking: Open/close hydraulics
• Release: Triangle key
• Impact reaction: Hydraulic clutch
• Environmental conditions: 14 ÷ 140 °F (-10 ÷ 60°C)
• Protection rating: IP57
• Manufacturer's warranty: 2 years

The BFT P935011-00013 is a professional-grade hydraulic gate operator built to perform reliably in intensive-use environments.
