Cellgate E1ATT Single Door LTE Access Controller

Overview

The Cellgate E1ATT is a single door LTE access controller built for one entry point. It ships with both AT&T and Verizon SIMs, and also supports VPN one-step connectivity. The aluminum alloy frame and steel powder coated enclosure deliver a strong, lightweight housing that resists corrosion and physical impact. A backlit numeric keypad with toughened glass front ensures reliable operation day or night.

Key Features

• Credential Types: Supports DESFire® EV3 RFID cards, fobs, or remotes with encryption and protection against cloning and credential theft; also supports HID credentials
• Bluetooth 5.0 Hands-Free Entry: Users can unlock via smartphone without contact using the CellGate app
• QR Code Access: Generate and share time-limited access for visitors, deliveries, or one-time entries
• PIN Code Access: Keypad-based access for guests, temporary users, or backup access
• 1 Wiegand 26-bit Input: Single Wiegand input for straightforward installation
• Single Relay Operation: One relay output for controlling the entry point
• 1 Digital Input & 1 REX Input: Monitor entry point status; REX input integrates an exit button or motion sensor; alerts for forced entry or tamper events
• CellGate App: Remotely open/close or set a hold-open period from iOS or Android; prop-open notifications sent if a gate or door is left open longer than 3 minutes; push notifications on all access attempts (if desired)
• LTE Connectivity: Ships with both AT&T and Verizon SIMs; or VPN one-step connectivity

Specifications

• Dimensions: W 4.7" x H 6.55" x D 1.55"
• Power Supply: 12V DC
• Enclosure: Aluminum alloy frame, steel powder coated enclosure
• Keypad: Backlit numeric keypad with toughened glass front
• Wiegand Input: 1 x Wiegand 26-bit
• Relay: Single relay operation
• Inputs: 1 digital input, 1 REX (Request to Exit) input
• Bluetooth: 5.0
• Supported Credentials: DESFire® EV3, HID, QR Code, PIN Code, Bluetooth
• Cellular: AT&T & Verizon LTE (both SIMs included)
• App Compatibility: iOS and Android

Compatibility

• Supports DESFire® EV3 and HID credentials
• AT&T & Verizon LTE networks
• CellGate app on iOS and Android

The Cellgate E1ATT delivers flexible, multi-credential access control with cellular connectivity for reliable single-door management.
