Cellgate E1HIDVZN Single Door LTE Access Controller
The Cellgate E1HIDVZN is a single door LTE access controller supporting Bluetooth 5.0, QR Code, PIN, and HID credentials with AT&T and Verizon LTE connectivity via included dual SIMs.
Overview
The Cellgate E1HIDVZN is a single-entry-point LTE access controller built for reliable, modern access control. Its aluminum alloy frame and steel powder coated enclosure deliver a strong, lightweight, corrosion-resistant housing measuring W 4.7" x H 6.55" x D 1.55". The unit ships with both AT&T and Verizon LTE SIMs and also supports VPN one-step connectivity, giving installers flexible deployment options.
Key Features
- Dual LTE Connectivity: Ships with both AT&T and Verizon SIMs; also supports VPN one-step connectivity.
- Bluetooth 5.0 Hands-Free Entry: Allows users to unlock entry points with a smartphone — no physical contact required.
- QR Code Access: Generate and share time-limited access for visitors, deliveries, or one-time entries without physical credentials.
- PIN Code Access: Backlit numeric keypad with toughened glass front enables keypad-based access day or night.
- HID Credential Support: Compatible with HID cards, fobs, and remotes via the included Wiegand 26-bit input.
- 1 Wiegand Input: Single Wiegand 26-bit input for credential reader integration.
- Single Relay Operation: Straightforward single-relay output for one entry point.
- 1 Digital Input & 1 REX Input: Monitor entry point status, receive forced-entry or tamper alerts, and integrate an exit button or motion sensor.
- CellGate App (iOS & Android): Remotely open or close, set hold-open periods, and receive push notifications on all access attempts.
- Prop-Open Notifications: Alerts are sent if an entry point has been left open longer than 3 minutes.
- TrueCloud Connectâ„¢: Cloud-based storage of access transactions, photos, and access control data.
Specifications
- Model: E1HIDVZN
- Brand: Cellgate
- Entry Points Supported: 1
- Dimensions: W 4.7" x H 6.55" x D 1.55"
- Power Supply: 12V DC
- Wiegand Inputs: 1 (26-bit)
- Relay: Single relay operation
- Digital Input: 1
- REX Input: 1
- Bluetooth: 5.0
- LTE Networks: AT&T and Verizon (dual SIMs included)
- Enclosure: Aluminum alloy frame with steel powder coated enclosure
- Credential Types: Bluetooth, QR Code, PIN, HID cards/fobs/remotes,
Compatibility
- CellGate app compatible with iOS and Android smartphones.
- Compatible with HID credentials (cards, fobs, remotes).
- Supports Wiegand 26-bit readers.
The Cellgate E1HIDVZN delivers versatile, cloud-connected single-door access control with multiple credential options and cellular redundancy for professional installations.
