Cellgate E1VZN Single Door Cellular LTE Controller

Overview

The Cellgate E1VZN is a single door cellular LTE access controller operating on the Verizon network. It features an aluminum alloy frame and steel powder coated enclosure for a strong, corrosion-resistant housing, paired with a backlit numeric keypad with toughened glass front for reliable day-or-night operation. This model supports DESFire® EV3 credentials only — for HID credential support, a different model is required.

Key Features

• DESFire® EV3 Credentials: Supports DESFire® EV3 RFID cards, fobs, or remotes with encryption and protection against cloning and credential theft
• Bluetooth 5.0 Hands-Free Entry: Users can unlock via smartphone without contact using the CellGate app
• QR Code Access: Generate and share time-limited access for visitors, deliveries, or one-time entries
• PIN Code Access: Keypad-based entry for guests, temporary users, or backup access
• 1 Wiegand 26-bit Input: Single Wiegand input for straightforward installation
• Single Relay Operation: One relay output for controlling the entry point
• 1 Digital Input & 1 REX Input: Monitor entry point status; REX input integrates an exit button or motion sensor; alerts for forced entry or tamper events
• CellGate App: Remotely open/close or set a hold-open period from iOS or Android; prop-open notifications sent if a gate or door is left open longer than 3 minutes; push notifications on all access attempts (if desired)
• VPN One-Step Connectivity: Supports VPN one-step connectivity in addition to cellular LTE

Specifications

• Dimensions: W 4.7" x H 6.55" x D 1.55"
• Power Supply: 12V DC
• Enclosure: Aluminum alloy frame, steel powder coated enclosure
• Keypad: Backlit numeric keypad with toughened glass front
• Wiegand Input: 1 x Wiegand 26-bit
• Relay: Single relay operation
• Inputs: 1 digital input, 1 REX (Request to Exit) input
• Bluetooth: 5.0
• Supported Credentials: DESFire® EV3, QR Code, PIN Code, Bluetooth
• Cellular: Verizon LTE
• App Compatibility: iOS and Android

Compatibility

• Supports DESFire® EV3 credentials (HID requires a different model)
• Verizon LTE network
• CellGate app on iOS and Android

The Cellgate E1VZN delivers secure, single-door access control with Verizon LTE cellular connectivity and multi-credential support.
