Cellgate E4VZN Entria Four Door Access Controller
The Cellgate E4VZN is a 4-door access controller with cellular or ethernet connectivity, supporting QR codes, PIN codes, Bluetooth, and DESFire® EV3 or HID credentials — managed from anywhere via TrueCloud Connect.
Overview
The Cellgate E4VZN Entria Four Door Access Controller delivers powerful, cloud-managed access control for business and multi-family properties. Choose between Verizon or AT&T cellular LTE connectivity or wired ethernet, and manage the entire system remotely through TrueCloud Connect™, hosted on Microsoft Azure. Locally stored credentials ensure reliable access even when cloud connectivity is unavailable.
Key Features
- Entry Point Credential Restrictions: Assign different credential restrictions by entry point for individuals or groups.
- Integrated Camera Support: Supports three (ethernet) or four (cellular) external cameras for visual verification at visitor access points.
- App-Controlled Entry: Open doors and gates using keycards, fobs, or the CellGate app — compatible with CG Readers and 3rd-party 26-bit Wiegand readers.
- Connectivity Flexibility: Choose Verizon or AT&T cellular LTE, or wired ethernet.
- Locally Stored Credentials: Access remains operational even if cloud connectivity is unavailable.
- Four Wiegand 26-bit inputs and 8 programmable relays per controller for management of up to four access points with auxiliary outputs for locks, gate triggers, alarms, or status indicators.
- 4 digital inputs and 4 REX (Request to Exit) inputs for monitoring door status, forced entry, or tamper events at each access point.
- SurePath Ethernet-to-Cellular Failover (optional): Keeps the controller online during internet outages.
- Power Supply: 12V DC
CellGate App
- Open or close a gate or door remotely from the CellGate app.
- Set hold-open periods and capture photos from external cameras on demand.
- Prop-open notifications sent if a gate or door has been left open longer than 3 minutes.
- Push notifications sent to designated users on all access attempts (if desired).
- Compatible with iOS and Android smartphones.
Available Features with CG Readers
- PIN Code Access — Keypad-based access without physical credentials.
- Bluetooth 5.0 Hands-Free Entry — Unlock doors or gates hands-free via smartphone.
- QR Code Access — Generate and share time-limited access for visitors or deliveries.
- DESFire® EV3 or HID Credentials — High-security RFID credentials via key cards, fobs, or remotes.
TrueCloud Connect Administration
- Manage users, access codes, restrictions, scheduled openings and closures, and access attempt logs from anywhere.
- Event logs of all transactions plus photos from integrated cameras recorded and stored in TrueCloud Connect.
- Multiple locations managed via a single login.
Hardware
- Aluminum alloy frame — corrosion-resistant and impact-resistant.
- NEMA 3 rated — protection against dust, rain, sleet, and ice.
- Dimensions: W 6.5″ × H 15″ × D 4.5″
- Suitable for indoor and outdoor installations.
Compatible Readers
- CellGate INFINITY Reader
- CellGate HALO Reader
- CellGate DIGIT Keypad
- Any 26-bit Wiegand device
The Cellgate E4VZN provides centralized, cloud-managed access control with the flexibility and reliability demanded by professional installations.
