Cellgate AA1MLPE-2X-VZN W480 Telephone Entry System

Overview

The Cellgate AA1MLPE-2X-VZN is the W480 telephone entry system configured with three Wiegand 26-bit inputs, allowing up to 3 additional Wiegand devices to be added. It features a brilliant 8" color touchscreen — larger, brighter, and higher-contrast for improved performance in direct sunlight — and is managed through the TrueCloud Connect™ web portal and the CellGate app.

Key Features

• 8" color touchscreen — larger, brighter, higher-contrast display optimized for direct sunlight visibility
• Up to 1,500 directory listings — suitable for multi-family properties of all sizes
• Full numeric keypad supporting up to 10,000 local codes and 64,000 non-local codes
• 3 Wiegand 26-bit inputs — ideal for pedestrian gates, card readers, keypads, or wireless remotes
• Built-in HID card reader — compatible with RFID/proximity card access programs
• Built-in camera — provides live streaming video to residents via the CellGate app, captures still pictures on access attempts, and takes pictures on demand by designated users
• QR Code and PIN Code Visitor Passes — designated users can issue recurring, temporary, or one-time passes directly from the TrueCloud Connect™ web portal or CellGate app
• Telephone entry functionality — delivers voice calls to landlines or users without the CellGate app
• Sequentially calls up to 6 app video contacts and 3 voice-only numbers — maximizing the likelihood a visitor reaches someone
• VMI – Voice Mail Intelligence — system detects when a call reaches voicemail and automatically moves to the next number on the call list
• Pedestal mount or recessed mount options available

Specifications

• Display: 8" color touchscreen
• Directory Listings: Up to 1,500
• Local Codes: Up to 10,000
• Non-Local Codes: Up to 64,000
• Wiegand Inputs: 3 × 26-bit
• Hardware Dimensions (W480): Height 11.9", Width 6.1", Depth 4.7"

Compatibility

• Managed via the TrueCloud Connect™ web portal and the CellGate app
• Compatible with RFID/proximity card systems via built-in HID card reader

The Cellgate AA1MLPE-2X-VZN delivers advanced access control and visitor management in a single, professionally installed unit.
