Maximum Controls SUPER-ARM-2300 Commercial Actuator

Maximum Controls SUPER-ARM-2300 Commercial Linear Gate Actuator

The SUPER-ARM-2300 by Maximum Controls is engineered as a true heavy-duty commercial actuator. Its patented brake system allows the operator to retract with extreme force — when force exceeds 3 tons, the clutch releases upon impact and automatically resets, protecting the operator from vehicle strike damage during gate motion. The unit features a continuous duty, brushless motor, intelligent ramp-up and ramp-down for smooth operation, and a professional-grade control board designed for complex, high-traffic access control environments. Additional entrapment prevention devices are required.

Key Features

• Continuous duty cycle brushless motor
• Patented clutch release at over 3-ton impact — automatically resets after release
• Intelligent ramp-up and ramp-down for smooth gate operation
• 24VDC battery backup with (2) 7Ah batteries — up to 500 full cycles on backup; three selectable backup modes: open once, leave open, or leave closed
• Switchable 115/230 voltage selection
• On-board switch for solar mode enables 18 milliamp idle in sleep mode
• Direct gear drive — no internal chains, belts, or pulleys
• Stainless steel output shaft
• Corrosion protection: gold zinc and powder coated aluminum housing
• Steel cover with lock protects against intruders and vandalism
• High cycles at extreme temperature ranges: -4°F to 165°F (-20°C to +74°C) including battery backup without a heater
• Robust lightning protection up to 20KVolts and 10KAmps on all inputs and outputs (35 channels), including loop detector input connections
• Adaptive DSP motor control for advanced motion control
• Real time performance analyzer and event log (OBD PORT and Black Box)
• Magic Box enables low voltage wiring for remote power up to 1,000 ft
• Two selectable 16-position safety obstruction sensors, auto adaptable to gate weight and size, for independent control of open and close cycles
• Two independently adjustable closing speed controls with 16 positions each
• Dual motor overcurrent safety shut off
• Industry standard 10-pin loop rack for easy access and safety
• Separate external loop detector inputs for complex scenarios
• SAMS or PAMS sequencing compatible
• High traffic intuitive loop management system
• Advanced anti-tailgate feature
• Magnetic lock control relay outputs with selectable delay times
• Tamper alert relay output — triggers if gate is forced open
• Audible alarm if gate is tampered with or ERD is triggered
• Gate disable feature disables all inputs except fire department and Max Open input
• Built-in transaction buffer
• Gate-in-motion strobe output
• Gate status outputs for gate monitoring
• On-board three-button station
• On-board UL reset button
• Key activated jog function for emergency OPEN/CLOSE
• Gold contact input connections and automobile grade connectors
• Mechanical and electrical gate release functions
• UL 325/991 compliant Class I, II, III, and IV; CSA approved
• 2-year / 100,000-cycle limited manufacturer warranty

Suitable Gate Dimensions

• 8 ft gate up to 2,300 lbs
• 12 ft gate up to 2,000 lbs
• 16 ft gate up to 1,800 lbs
• 20 ft gate up to 1,500 lbs

Specifications

• Operational Voltage: 24VDC
• Power Source: 115/230VAC or 24VDC Solar
• Motor: 24 Volt DC, continuous duty, brushless
• Battery Backup: (2) 7Ah batteries, up to 500 full cycles
• Operational Temperature Range: -4°F to 165°F (-20°C to +74°C)
• Lightning Protection: Up to 20KVolts / 10KAmps — 35 channels
• Remote Power Wiring: Up to 1,000 ft via Magic Box
• Compliance: UL 325/991 Class I, II, III, IV; CSA approved
• Warranty: 2 years / 100,000 cycles limited manufacturer warranty
• Manufacturer Part Number: MAX-SUPER-ARM-2300

The Maximum Controls SUPER-ARM-2300 is built exclusively for installation by professional, experienced gate installers — delivering the security, reliability, and performance demanded by commercial access control applications.
