Maximum Controls MAX2200PRO-M Commercial Slide Gate Operator

Overview

The Maximum Controls MAX2200PRO-M with optional Metal Civer is a DSP-controlled brushless DC slide gate operator engineered for high-traffic gated communities, commercial and industrial facilities, and public storage applications. It handles gates up to 2,200 lbs and 60 ft in length, operating at a speed of 12" per second for UL Class I, II, III, and IV applications. The enclosure features a lockable cover with key lock release, constructed from quarter-inch UV-protected, high-impact polyurethane material for long-term structural stability and fade resistance. In most cases, the MAX2200PRO-M can be directly bolted onto concrete pads used by other widely installed gate operators.

Key Features

• Continuous duty, brushless DC motor equivalent to 1¼ HP AC motor
• Matrix-III board — solar-ready with built-in advanced solar regulator
• Adaptive DSP control for advanced brushless DC motion control
• 24VDC battery backup providing up to 200 full cycles on power failure; three selectable battery backup modes
• Intelligent ramp-up and ramp-down gate speed control with selectable short or long ramp-down
• Independent opening and closing speed control for primary and secondary
• 16 selectable programmable gate speeds
• Selectable open timer: 0 to 60 seconds with timer off option
• Direct gear drive — no internal chains, belts, or pulleys
• Heavy duty direct drive gear box size 60, 30:1 gear ratio
• Programmable virtual OPEN & CLOSE limits (auto-set on total power loss)
• Real-time performance analyzer and event log (OBD port and Black Box) — 8,000 events including error failure history
• LCD display reporting past and recent errors
• Robust lightning protection up to 20KVolts and 10KAmps on all inputs and outputs (44 channels) including loop detector input connections
• Operational temperature range: -4°F to 165°F (-20°C to +74°C) including battery performance without a heater
• Switchable 115/230 voltage selection
• Low voltage wiring for remote power-up up to 500 feet (no battery needed)
• High-traffic intuitive loop management system
• Advanced anti-tailgate features
• Tamper alert relay output triggers "on" if gate is forced open; audible alarm on tampering or ERD trigger
• Magnetic lock control relay outputs with selectable delay times
• Gate partial open recorder — programmable inputs for partial open cycles (high-traffic) and full open cycles (emergency vehicles)
• Optional chain drop sensor detects unauthorized chain drops when using magnets option
• Fire department compliance: gate auto-opens upon loss of AC power or battery depletion
• Gate status outputs for gate monitoring
• Built-in transaction buffer: 8,000 events plus error messaging file
• Motor overcurrent safety shut-off
• Corrosion protection via gold zinc coating and electrostatic powder coating
• Gold contact input connections and automobile-grade connectors
• Built-in current-limited 12VDC and 24VDC outputs
• On-board three-button station
• Electronic release: jog switch at front cover sliding window
• Includes 25 ft nickel-plated chain and brackets
• Hall Effect sensing
• Modular system design for ease of service
• 5-year limited manufacturer warranty

Specifications

• Model: MAX2200PRO-M
• Brand: Maximum Controls
• Operating Voltage: 24VDC
• Power Source: 115/230VAC switchable or 24VDC Solar
• Gate Capacity: 2,200 lbs
• Maximum Gate Length: 60 ft
• Gate Speed: ~12" per second
• UL Classifications: Class I, II, III, and IV
• Dimensions: 14.5"W x 19"D x 25.5"H; 7.5" chain height
• Shipping Weight: 158 lbs
• Gear Box: Size 60, 30:1 gear ratio
• Motor: Continuous duty brushless DC, equivalent to 1¼ HP AC
• Battery Backup: 24VDC, up to 200 full cycles
• Temperature Range: -4°F to 165°F (-20°C to +74°C)
• Lightning Protection: Up to 20KVolts / 10KAmps, 44 channels
• Event Log: 8,000 events
• Warranty: 5-year limited manufacturer warranty

Compatibility

The MAX2200PRO-M is compatible with existing installations and in most cases can be directly bolted onto concrete pads used by the most popular gate operators in the industry. With the Solar Combiner, up to 4 Solar Power Packs with 200W solar panels can be wired together to form a single-ended 24VDC supply source.

Note: Additional entrapment prevention devices are required. Installation must be performed by a professional gate installer — warranty and tech support apply only when installed by industry professionals.

The Maximum Controls MAX2200PRO-M delivers proven commercial-grade performance with advanced DSP control, comprehensive security features, and solar-ready capability for demanding high-traffic environments.
