Viking Access Systems VFLEXPCBU18 Control Board
The Viking Access Systems VFLEXPCBU18 is the orange-logo, post-2018 UL325-compliant VFLEX control board for Viking DC gate operators, featuring enhanced surge protection and advanced diagnostics.
Overview
The Viking Access Systems VFLEXPCBU18 is the current-production VFLEX control board for Viking DC gate operators. Identified by its orange logo, this board meets post-2018 UL325 standards and serves as the central controller for most Viking Access DC gate operator models in residential, commercial, and light-industrial gate applications. Note: this board requires a monitored photoeye.
Key Features
- Compatible with most Viking Access DC operators, including R6, F1, K2, L3, G5, T21, and X390
- On-board LCD diagnostics displaying real-time status, cycle counts, motor current, and fault codes
- Adaptive motor control — adjusts torque and speed based on gate load and temperature
- Surge protection rated up to 20,000 volts / 10,000 amps
- Battery backup support for up to 400 full cycles on a 600 lb gate
- UL325 compliant with obstruction sensing and monitored safety device support
- Operating temperature range: -20°F to 160°F with thermostat-controlled heater
- Direct-mounted installation
Specifications
- Operating Voltage: 24VDC
- Input Power: 120/240VAC single-phase
- Accessory Output: 24VDC at 750mA
- Surge Protection: Up to 20,000 volts / 10,000 amps
- Battery Backup: Up to 400 full cycles on a 600 lb gate
- UL Certification: UL325 (post-2018)
- Mounting Type: Direct-Mounted
- Installation Type: Residential | Commercial
Compatibility
- Compatible with most Viking Access DC operators including: R6, F1, K2, L3, G5, T21, and X390
- Excludes H-10 models
- Requires a monitored photoeye
The Viking Access Systems VFLEXPCBU18 is the post-2018 UL325 VFLEX control board solution for professionals maintaining or upgrading Viking Access DC gate operator systems.
