EMX Industries 2803-2 Controller for VMD-202 Free Exit Probe
The EMX Industries 2803-2 is the controller for the VMD-202 free exit probe, featuring a water-tight, direct burial compatible probe assembly and settings retained in non-volatile memory to survive power failures.
Overview
The EMX Industries 2803-2 controller powers the VMD-202 vehicle motion detector — a single-piece probe unit designed to be buried next to a driveway. The probe and its electronics are housed in a slim design, and the probe assembly and cable are water-tight and direct burial compatible. Settings are stored in non-volatile memory, so sensitivity configurations are retained even after a power failure. The unit is supplied with a 50-ft. lead.
Key Features
- Probe assembly and cable are water-tight and direct burial compatible
- Settings stored in non-volatile memory — retained through power failures
- Accepts a wide range of power inputs: 12-39 VDC or 12-27 VAC
- Low current consumption: 70 uA standby and 25 mA activated — suitable for solar power applications
- 10 sensitivity settings programmable via the optional VMD202-R sensitivity remote (sold separately)
- Supplied with a 50-ft. lead
- Available in two connector versions: plug-in harness connector (manufactured before 9/2020) and terminal block connector (manufactured after 9/2020)
Specifications
- Power: 12-39 VDC or 12-27 VAC
- Current: 70 uA standby / 25 mA activated
- Relay: Form C (SPDT) 1 A @ 24 VDC, 1 A @ 120 VAC
- Operating Temperature: -30°C to 70°C (-22°F to 158°F), 0 to 95% relative humidity
- Dimensions (VMD202-R): 3.0 x 0.9 x 2.75 in
- Probe Dimensions: 1 x 24 in
- Probe Cable: 5 wire direct burial
- Material: ABS Plastic (VMD202-R), PVC (Probe)
Optional Accessory
- VMD202-R sensitivity remote — sold separately. Can be removed after programming and reused across multiple installations.
The EMX Industries 2803-2 delivers reliable free-exit detection in a durable, burial-rated design built for long-term outdoor use.
