Linear SGEKDC DC Gate Edge Radio Kit Mon 10K
The Linear SGEKDC is a DC Gate Edge Radio Kit approved for APeX2 operators, including one SGET transmitter and one SGER receiver for wireless safety edge monitoring with a 10K exterior safety edge sensor.
Overview
The Linear SGEKDC DC Gate Edge Radio Kit is approved for use with APeX2 operators and includes one SGET transmitter and one SGER receiver. In a typical installation, the SGET is mounted on a motorized gate or barrier arm and wired to a 10K exterior safety edge sensor. The sensor presents a closed circuit across the connecting wires when an object is contacted during the closing cycle. To ensure full compatibility with all gate edge supervision features, Miller gate edge sensors with 10K only are recommended.
Key Features
- Approved for APeX2 operators
- Includes one SGET transmitter and one SGER receiver
- Compatible with 10K exterior safety edge sensors
- Each transmitter is factory pre-set to a unique code — no coding switch required
- Receiver is programmed by sending a signal from the transmitter(s) to be used
- Receiver retains memory even without power
- Receiver will activate only from memorized transmitters
Specifications
- Receiver operating voltage: 10.5–30 volts DC
- Relay contact rating: 5 amps @ 32 volts AC/DC, NEC Class 2 circuit
- Sensor resistance: 10K
Compatibility
- Approved for Linear APeX2 operators
- Recommended sensor: Miller gate edge sensors, 10K only
The Linear SGEKDC provides reliable wireless safety edge monitoring for professional gate installations requiring APeX2 compatibility.
