All-O-Matic SL-45-DC-PRO DC Slide Gate Operator
The All-O-Matic SL-45-DC-PRO is a continuous-duty DC slide gate operator rated for gates up to 800 lbs. and 30 feet, featuring a brushless motor, integrated battery backup, and solar compatibility. Made in the USA.
Overview
The All-O-Matic SL-45-DC-PRO is a residential DC slide gate operator designed for gates up to 800 lbs. and 30 feet in length. Its 24VDC brushless motor with planetary gearbox delivers smooth, quiet, and powerful operation while requiring zero maintenance. The integrated battery backup system provides up to two weeks of uninterrupted operation during a power outage. Compatible with 115/230 VAC single-phase power or a 24VDC solar panel, the SL-45-DC-PRO offers flexible installation options. Made in the USA.
Key Features
- Continuous duty brushless DC motor with planetary gearbox
- Integrated battery backup with (2) 7Ah 12VDC batteries — up to two weeks of operation during power outages
- Battery backup capacity: 250 cycles on a 600 lb. gate
- Solar power compatible (24VDC solar panel)
- Programmable relay and leaf delay
- Slow start/stop algorithm
- Includes 2 photo eyes
- Emergency release: push open in the event of a power failure
- Breaker requirement: 20 amp dedicated
- 5-year residential limited manufacturer warranty
Specifications
- Max Gate Weight: 800 lbs.
- Max Gate Length: 30 feet
- Operational Voltage: 24VDC
- Power Input: 115/230 VAC single phase or 24VDC solar panel
- Motor: 24VDC brushless with planetary gearbox
- Gate Speed: 12" per second
- Duty Cycle: Continuous
- Gearbox Ratio: Approx. 29:1
- Temperature Range: -40° to 160°
- Dimensions (W x L x H): 11" x 14.5" x 15.5"
- Chain Size: 41NP (20' included)
- Main Sprocket Size: 41B15X5/8
- Limit Shaft Sprocket: 41B10X5/8
- Manufacturer Part Number: SL45-DC-PRO
The All-O-Matic SL-45-DC-PRO delivers reliable, low-maintenance slide gate automation built for residential applications.
