BD Loops RL 24-40 4x8 or 6x6 Preformed Direct Burial Inductance Loop, 40' Lead-In

BD Loops RL 24-40 is a preformed direct burial inductance loop engineered for reliable vehicle detection in underground installations. The loop has a 24’ perimeter and fits a 4x8 or 6x6 loop pattern, with a 40 ft lead-in for routing back to the loop detector. The rigid loop section is constructed using solid 16 AWG copper wire, helping it stay properly positioned during concrete pours. A durable outer jacket tightly binds and protects the conductors for added reliability. This design minimizes air pockets that can contribute to phantom detections caused by vibration. Each loop is tested multiple ways before leaving the factory to ensure dependable performance.

Gate Design Tools

Use these BD Loops calculators to size your direct burial loop and estimate sand needed for your gate setup:

• Loop Size Calculator (Loopalator)
• Sand Needed Calculator
