Transmitter Solutions DOLKSF1000 Stand Alone Keypad

Overview

The Transmitter Solutions DOLKSF1000 Dolphin Stand Alone Surface Mount Keypad delivers reliable access control with capacity for up to 1,000 users. Housed in a zinc-alloy enclosure, it is rated for indoor use and can also be used outdoors when protected from the elements. The unit operates on 12–24VDC and draws only 50mA, making it an efficient choice for access-controlled entry points.

Key Features

• 1,000 User Capacity
• Backlit Keypad — 12-key (3×4) layout
• Multi-color LED Status Display
• One Programmable Relay Output (NO, NC, Common) — timed or latching
• Latch Mode to hold a door or gate open
• Anti-Tamper Alarm
• Low Power Consumption — 50mA

Specifications

• Model: DOLKSF1000
• User Capacity: 1,000
• Operating Voltage: 12–24VDC
• Relay: One (NO, NC, Common) — Timed or Latching
• Keypad: 12 Key (3×4)
• Wiring Connections: Relay Output, Exit Button
• Temperature Rating: -30°C to 60°C (-22°F to 140°F)
• Dimensions: L: 4¾" × W: 3" × H: 1" (inches)
• Weight: 17.2 oz.
• Housing: Zinc-Alloy Enclosure
• IP Rating: Indoor (Outdoor — if protected from the elements)

The Transmitter Solutions DOLKSF1000 is a dependable stand alone keypad solution for professionals requiring straightforward, high-capacity access control.
