DoorKing 2108-090 Residential Video Entry System
The DoorKing 2108-090 is a cloud-based video entry system featuring a built-in IP camera, broadcast calling to up to 4 phones simultaneously, and control of up to 3 entry points via internet or cellular connection.
Overview
The DoorKing 2108-090 is a cloud-based residential video entry system that allows users to grant guest access from virtually anywhere. It supports video or voice calls in broadcast mode, reaching up to four phone numbers at once when the call button is pressed. The system connects via a user-provided internet connection or an optional cellular connection, and all settings are managed through any standard web browser — no proprietary software required. Programming and user data are shared in the cloud, with updates reflected in real time.
Key Features
- Built-in IP camera for video calling
- DKS Video Calling app supported
- Broadcast calling — up to 4 phone numbers simultaneously
- Supports 10 residents, with a maximum of 4 phone numbers per resident
- Controls up to 3 entry points (relays)
- Entry codes configurable as 4 or 5 digits
- Browser-based programming via laptop, tablet, or smartphone
- Cloud-based platform — all programming updates appear as they occur
- Do Not Call schedule
- Hold Open schedule
- Entry Code schedule
- Relay (Door/Gate) status: Closed – Open – Held Open
- Each relay (entry point) can be individually named
- Independent relay strike times
- Relay control: Close – Open – Hold Open
- Built-in paper directory for up to 10 names
- Backlit metal keypad
- Backlit metal push-to-call button
- Stainless steel faceplate
- Galvanized steel sub plate
- Flat surface mount configuration
- 2-year warranty
Specifications
- Power: 16VAC, 20VA transformer provided
- Backup Power Input: 12VDC
- Relays: Three (3) Type C relays, 1A max
- Operating Temperature: 10°F to 145°F (-12°C to 62°C)
- Shipping Weight: Approximately 15 lb (7 kg)
- Connectivity: User-provided internet connection required; cellular connection available if internet is not possible (additional fee applies)
- Standard Residential Package Registration required
Compatibility
- Cellular connection requires external cellular kit — activation through DoorKing
The DoorKing 2108-090 delivers professional-grade video entry control with flexible connectivity and cloud-based management for residential access applications.
