Viking Access Systems X390DLK Dual Leaf Kit
The Viking Access Systems X390DLK is a complete dual leaf swing gate operator kit designed for gates up to 600 lbs. and 14 ft. per arm, with a normal operating speed of 10–13 seconds per 90°.
Overview
The Viking Access Systems X390DLK is a complete dual leaf swing gate operator kit built around the X-390 automatic swing gate opener. Each arm supports gates up to 600 lbs. and 14 ft. in length. The system meets the most current UL325 Class I, II, III, and IV safety standards and includes a V-Flex control board with LCD display. The operator is solar efficient, ready for low voltage wiring, and can be installed on a column. An integrated heater and battery backup are included.
Key Features
- Gate type: Dual Swing Gate
- Max gate length: 14 ft. per arm
- Max gate weight: 600 lbs. per arm
- Normal operating speed: 10–13 seconds per 90°
- Monitoring inputs: 2, with up to 4 devices per input
- Battery backup: 400 continuous cycles
- Integrated heater included
- Solar efficient design
- Column-mount installation compatible
- Plug and Play connection for compatible Viking wireless products
- Manufacturer warranty: 3 years
Kit Includes
- (2) VA-X390 — X-390 Swing Gate Operator
- (1) VA-ECUD2 — ECU Dual Controller for Kits
- (1) FA-XR2C — 433 MHz Receiver
- (2) FA-XT4RC — 433 MHz RC Transmitter
- (1) FA-XP30-10K — Photocell 10K Resistor
- (2) FA-XP30AC — Photocell Adapter
- (1) DJBK — Junction Box
- (40 ft) VA-CB16 — 6-Conductor Cable, 16 AWG Shielded
Compatibility
- Viking Konnect — Wireless kit providing wireless communication when the application requires two single ECUs
- Viking Monitor — Grants remote access to control board settings, controls, gate status, diagnostics, and error notifications via any compatible computer or hand-held device
The Viking Access Systems X390DLK delivers a complete, professional-grade dual leaf swing gate solution engineered to meet current UL325 safety standards across a wide range of applications.
