AES EL00IG-RAD-K E-Loop Inground Commercial Radar Loop Kit
The AES EL00IG-RAD-K is an inground wireless presence mode loop kit featuring dual sensor technology — Magnetic field and Radar detection — with 128-bit encryption and up to 50 yards range. Kit includes e-Loop, transceiver, and magnet.
Overview
The AES EL00IG-RAD-K E-Loop Inground Commercial Radar Loop Kit recesses flush into the pavement for a clean, unobtrusive installation that eliminates tripping hazards. Designed for high-traffic commercial environments such as busy parking lots and loading docks, it combines a compact profile with robust construction. The kit ships in presence mode and includes the e-Loop, transceiver, and magnet.
Key Features
- Dual sensor technology — Magnetic field and Radar detection
- Inground, flush-mount installation — 2.1" diameter x 3.4" high, rated IP68
- Not affected by ground movement
- 128-bit encryption for high security
- 14,500 mAh battery providing up to 6–10 years of battery life
- Top access for battery replacement
- Up to 50 yards wireless range
- Quick and easy installation
Included e-Trans50 Transceiver Specifications
- Voltage: 10–36V DC
- Standby current draw: 4.5 mA; Active: 30 mA
- Frequency: 433.39 MHz
- Remote storage: 50 remotes, 4 x e-Loops, 4 x Keypads, 4 x Entry Buttons
- Relay: 1-amp contact rating, COM and N/O connections x 1 relay
- Modes: Pulse, Latch, and Hold
The AES EL00IG-RAD-K delivers reliable, encrypted wireless loop detection with a discreet inground profile built for demanding commercial applications.
