AES ETRANS200 LCD Transceiver

Overview

The AES ETRANS200 E-TRANS 200 LCD Transceiver is a high-end access control solution designed for commercial multi-unit complexes and home systems. With simple menu functions accessible via an LCD display, it supports up to 200 code storage entries with remote ID selection, and offers a high sensitivity 433 MHz -126 dBm receiver with a 20 dBm transmission output.

Key Features

• Simple to use menu functions with LCD display
• 200 code storage with remote ID selection — ideal for unit applications
• Wide input voltage range: 10V to 36V AC/DC
• 2 relay outputs with selectable Pulse, Hold, or Latch mode
• Selectable ultra-low standby power consumption of only 4.5 mA — ideal for solar applications
• Ability to delete individual remote devices
• Unique lock-out feature allowing you to lock out entry buttons, e-Loops, and keypads using the lock and unlock function on the e-Remote
• Ability to connect to the e-Loop to access menus and change settings
• Test mode allows testing of relay outputs, signal strength, and interference
• External SMA connector to allow for the connection of different antennas

Specifications

• Input Voltage: 10V to 36V AC/DC
• Standby Current: 4.5 mA (selectable ultra-low)
• Receiver Sensitivity: 433 MHz -126 dBm
• Transmission Output: 20 dBm
• Code Storage: 200
• Relay Outputs: 2 (Pulse, Hold, or Latch mode)
• Antenna Connector: External SMA

Compatibility

• Compatible with the e-Loop for menu access and settings changes
• Compatible with the e-Remote for lock and unlock functions
• Kits available including Transmitter, 4 E-TX Fobs, and Antenna

The AES ETRANS200 delivers flexible, reliable access control for both solar-powered installations and commercial multi-unit environments.
