AES ETRANS50 Transceiver
SKU
ae-etrans50
The AES ETRANS50 is a bidirectional wireless access control transceiver featuring a wide 10–36V DC voltage range and storage for 50 remotes, 4 e-Loops, 4 Keypads, and 4 Entry Buttons.
Overview
The AES ETRANS50 E-TRANS 50 Transceiver delivers bidirectional wireless access control for gate and door applications. Its compact design offers exceptional range, and an SMA connector is included for optional long-range antenna connection.
Key Features
- Wide voltage range: 10–36V DC
- Exceptionally low current draw: 4.5 mA standby, 30 mA active
- Compact design with exceptional range
- SMA connector for optional long-range antenna connection
- Multiple operating modes: Pulse, Latch, and Hold
- Relay: 1-amp contact rating, COM and N/O connections x 1 relay
Specifications
- Model: ETRANS50
- Frequency: 433.39 MHz
- Voltage: 10–36V DC
- Current Draw: 4.5 mA standby / 30 mA active
- Remote Storage: 50 remotes, 4 x e-Loops, 4 x Keypads, 4 x Entry Buttons
- Relay: 1-amp contact rating, COM and N/O connections x 1 relay
The AES ETRANS50 is a reliable, low-power transceiver built for flexible wireless access control installations.
