FAAC 202025 E024U Control Board

Overview

The FAAC 202025 E024U Control Board is a replacement control board engineered to operate numerous FAAC low voltage swing gate operators. It includes a built-in 24V DC voltage backup power supply and is compliant with UL325 and UL991 safety standards. This board requires the use of monitored safety devices for entrapment protection.

Key Features

• UL325 and UL991 safety standard compliant
• Powerful and efficient switching power supply
• Easy programming with trimmers and dip switches
• One pushbutton automatic time learning
• Self resetting fuses
• Built-in battery backup
• Low current idle mode to preserve battery
• Opening and closing delays selectable for overlapping gates
• Speed and force adjustable with trimmers
• Control board firmware upgradable via USB
• Solar powered option available
• Motor Output Current Max: 7 A
• Accessory Power: 24 Vdc - 500 mA

Specifications

• Input Voltage: 115 VAC (+10% -6%)
• Input Power: 400 W max - 4 W stand by
• Operating Temperature: -4°F to 131°F (-20°C to +55°C)
• Dimensions: 17.5 x 15.5 x 6.2 in (445 x 393 x 157 mm)
• Protection Class: NEMA type 3, 3R, 4, 4X, 12 and 13

Compatibility

The FAAC 202025 is compatible with the following FAAC gate openers:

• FAAC 390 Swing Gate Opener
• FAAC 415 Swing Gate Opener
• FAAC 770 Swing Gate Opener
• FAAC S418 Swing Gate Opener
• FAAC S450H Swing Gate Opener
• FAAC S800H Swing Gate Opener

Order the FAAC 202025 E024U Control Board today to restore reliable, code-compliant operation to your FAAC swing gate system.
