Viking Access Systems E4 Solar Ready Linear Arm Gate Operato
The Viking Access Systems E4 is a residential swing gate operator featuring a 24VDC operational voltage, solar-ready design, and support for gates up to 850 lbs / 10' or 550 lbs / 16' with a 3-year limited manufacturer warranty.
Overview
The Viking Access Systems E4 Solar Ready Linear Arm Gate Operator is a residential swing gate operator built for reliability and installation versatility. It supports both AC mains and solar power input, includes battery backup with batteries, and features a convenient manual release handle with pre-wiring for straightforward installation. The E4 carries UL compliance and a 3-year limited manufacturer warranty.
Key Features
- Direct solar input with dedicated port for solar panel
- Battery backup included — two 6Ah batteries included, up to 400 continuous cycles on battery backup
- Single control board designed to operate a single or dual gate — no additional boards required
- Low power consumption board with automatic sleep mode
- Efficient battery charger
- Mechanical disengagement allows the gate to be moved freely
- Advanced lightning strike protection up to 20,000 volts / 10,000 amps with on-board surge protection
- UV powder coating on aluminum alloy chassis for corrosion and weather resistance
- Convenient manual release handle
- Pre-wired for easy and quick installation
- UL compliant
- Important: An approved monitored secondary entrapment protection sensor is required by UL 325. At least one monitored "10K Resistor Based" sensor must be connected or the operator will not run. Any UL 325-approved monitored 10K resistor-based photoelectric beam sensor or edge sensor may be used.
Specifications
- Operational Voltage: 24VDC, 1/2 HP
- Main Power Source: 115/230VAC – 24V AC/DC
- Operating Speed: 12–16 seconds per 90°
- Maximum Operating Angle: 110°
- Maximum Gate Capacity: 850 lbs / 10' or 550 lbs / 16'
- Battery Backup Cycles: Up to 400 continuous cycles
- Maximum Duty Cycle: 100% Continuous Cycle
- Operating Temperature: -20°F up to +160°F
- Lightning Strike Protection: Up to 20,000 volts / 10,000 amps
- Warranty: 3-year limited manufacturer warranty
The Viking Access Systems E4 delivers a solar-compatible, UL-compliant solution for residential swing gate applications with robust weather protection and built-in battery backup.
