Viking Access Systems E4K Swing Gate Operator Single Kit
The Viking Access Systems E4K is a residential linear arm swing gate operator supporting gates up to 850 lbs / 10' or 550 lbs / 16', backed by a 2-year manufacturer's warranty and UL compliance.
Overview
The Viking Access Systems E4K Swing Gate Operator Single Kit is recognized as a cost-effective residential linear arm actuator. It supports a maximum gate capacity of 850 lbs / 10' or 550 lbs / 16' per gate leaf. The E4K includes a convenient manual release handle and arrives pre-wired for efficient installation by a licensed installer. Low voltage wiring readiness provides installation versatility and accuracy. Brackets are designed to give installers the choice of welding or bolting on, offering added flexibility in the field.
Key Features
- E-4 Control Board compatible with single and dual gates
- Maximum operating speed of 12–16 seconds
- Manual release handle for convenient access
- Pre-wired for quick installation by a licensed installer
- Ready for low voltage wiring
- Lightning strike protection: 10,000 Amps / 20,000 Volts
- Choice of weld-on or bolt-on bracket mounting
- UL compliant
- 2-year manufacturer's warranty
Specifications
- Maximum Gate Capacity: 850 lbs / 10' or 550 lbs / 16'
- Operating Temperature: -20°F up to 160°F
- Maximum Operating Speed: 12–16 seconds
- Lightning Strike Protection: 10,000 Amps / 20,000 Volts
- Warranty: 2-year residential manufacturer's warranty
- Compliance: UL listed
Kit Includes
- (1) VA-E4K — E4 Operator Single Kit
- (1) VA-E4S — E4 Secondary Gate Arm / Motor
- (1) FA-XP30-10K — Photocell, 10K send and receive
- (2) FA-XT4RC — 433 MHz RC Transmitter
- (1) FA-XR2C — 433 MHz 2-Channel Receiver
The Viking Access Systems E4K delivers reliable residential swing gate automation with the components and flexibility professionals need for a complete installation.
