Viking Access Systems VA-ECUE4-2 ECU Dual Controller for Kit

Overview

The Viking Access Systems VA-ECUE4-2 ECU Dual Controller is engineered for E4 compatible gate operator kits. The unit operates on 24VDC and supports multiple power sources including AC mains, 24V solar panel input, and battery backup. Two 6Ah batteries are included. The enclosure is aluminum construction with a powder-coated finish, IP54-certified ingress protection, post-mount options built-in, pre-punched holes for conduit, and a padlock latch.

Key Features

• UL 325 compliant
• Adaptive motor control with adjustable speed control
• Two monitoring inputs with up to 4 devices per input
• Lightning strike protection
• 24V solar panel input
• 24V battery charger — two 6Ah batteries included
• Low voltage plug-in transformer included
• Two AC receptacles
• 120V toroid transformer optional
• Sleep mode
• Big box option available
• Aluminum, powder-coated enclosure with IP54-certified ingress protection
• Post-mount options built-in; pre-punched holes for conduit
• Padlock latch
• 3-year manufacturer's warranty

Specifications

• Compatible Models: E4
• Operating Voltage: 24VDC
• Voltage / Current: 120VAC – 2.0A or 240VAC – 1.0A (each motor)
• Main Power Frequency: 50Hz / 60Hz
• Main Power Fuse: 4A Timed (with 120V option only)
• Alternative Power Source: 24VAC / VDC (60VA) or Solar
• Accessory Power: 24VDC – 750mA
• Power Consumption (Sleep): 6mA
• Motor Current (Typical): 2.0A
• Operating Temperature: -20°F (-28°C) to 131°F (55°C)
• Dimensions — Standard Box (L x D x H): 16.375 x 6.25 x 17.875 in
• Dimensions — Big Box (L x D x H): 18.75 x 8.125 x 18.2 in

Compatibility

The VA-ECUE4-2 is compatible with Viking Access Systems E4 gate operator kits.

The Viking Access Systems VA-ECUE4-2 is a reliable dual controller solution for E4 kit installations requiring flexible power options and robust enclosure protection.
