Viking Access Systems VA-ECUMSNXSLR2 ECU Dual Controller Sol
The Viking Access Systems VA-ECUMSNXSLR2 is a dual controller solar ECU designed for the G5 Solar gate operator, featuring a 3-year manufacturer's warranty and UL 325 compliance.
Overview
The Viking Access Systems VA-ECUMSNXSLR2 is the ECU dual controller solar unit built for the G5 Solar gate operator. Operating on 24VDC with a 12VDC power source, this controller is UL 325 compliant and housed in a rainproof, powder-coated aluminum enclosure with a lockable door. It supports a built-in voltmeter, onboard display, and is engineered for reliable solar-powered gate control. Backed by a 3-year manufacturer's warranty.
Key Features
- UL 325 compliant
- Two monitoring inputs with up to 4 devices per input
- Onboard display
- Built-in voltmeter
- Lightning strike protection
- 12V solar panel input
- 12V battery charger
- Solar panel switch
- Battery switch
- Big box accommodates up to a 35 Ah battery
- Aluminum construction, powder-coated finish
- Lockable door
- Rainproof enclosure
- Pre-punched holes for conduits
- Sleep mode
- Adaptive motor control
- Adjustable speed control
- Anti-tailgating feature
- Built-in 3A solar charge regulator
Specifications
- Compatible Models: G5 Solar
- Operating Voltage: 24VDC
- Main Power Fuse: 4A Timed
- Power Source: 12VDC
- Accessory Power: 24VDC – 750mA
- Power Consumption (Sleep): 19mA
- Motor Current (Typical): 2.0A
- Operating Temperature: -4°F (-20°C) to 160°F (71°C)
- Dimensions – Standard Box (L x D x H): 16.75 x 6.125 x 15.625 in
- Dimensions – Big Box (L x D x H): 18.75 x 8.125 x 18.2 in
- Manufacturer's Warranty: 3 years
Compatibility
- Compatible with Viking Access Systems G5 Solar gate operator
The Viking Access Systems VA-ECUMSNXSLR2 delivers dependable solar gate control performance with professional-grade features and a robust, weatherproof design.
