MMTC 1KXL-O Exterior Surface Mount Hold Open Keyswitch
SKU
mmtc-1kxl-o
The MMTC 1KXL-O is a surface-mounted exterior keyswitch with Open and Close operation, housed in an aluminum die-cast, NEMA 3R, 4, and 12-rated enclosure with a 5-pin mortise-type cylinder.
Overview
The MMTC 1KXL-O delivers straightforward keyed control of gate systems with simple Open and Close operation. Power activates when the key is turned to the Hold Open setting and deactivates when turned to the Close position. The unit is surface-mounted in an aluminum die-cast housing built to withstand a wide range of environmental conditions, and its NEMA 3R, 4, and 12-rated enclosure makes it well suited for exterior installations.
Key Features
- Open and Close operation via key turn
- NEMA 3R, 4, and 12-rated enclosure
- Surface-mounted installation
- Aluminum die-cast housing
- 5-pin mortise-type cylinder for enhanced security
Specifications
- Dimensions: 4 3/8" (H) x 4 1/8" (D) x 2 5/8" (D)
- Input Voltage: 110/115/120 AC (60 Hz, 1 Phase)
- Rating: 20 amp @ 125V AC or 15 amp @ 250V AC
- Color: Gray
- Mount Type: Surface Mount
The MMTC 1KXL-O is a reliable, security-focused keyswitch solution for exterior access control applications.
