Seco-Larm SK-91ERSD Extended Range Antenna

Overview

The Seco-Larm SK-91ERSD Extended Range Antenna is designed to expand the range of compatible Seco-Larm RF wireless installations up to 1,000ft (300m). Operating at 315MHz, this dipole-type antenna plugs directly into a connector on the receiver's motherboard, requiring no extra wiring.

Key Features

• Extends RF receiver range up to 1,000ft (300m)
• Plugs directly into a connector on the receiver's motherboard — no extra wiring needed
• RoHS compliant

Specifications

• Frequency: 315MHz
• Maximum Antenna Range: 984.3 ft (300,000 mm)
• Width: 8.54" (217mm)
• Height: 0.94" (24mm)
• Depth: 0.63" (16mm)
• Environmental Certification: RoHS

Package Contents

• Extended Range Antenna – 315MHz
• 9-foot cable
• Cable clamp
• Double-stick mounting tape

Compatibility

Compatible with the following Seco-Larm RF receivers:

• SK-910RBQ — Single-channel receiver
• SK-910RB2Q — Two-channel receiver
• SK-910R3Q — Three-channel receiver
• SK-910R4Q — Four-channel receiver

The Seco-Larm SK-91ERSD is a straightforward, tool-free upgrade for extending the wireless range of your existing compatible Seco-Larm RF receiver installations.
